Kinematics & hinges with multiple pivot joints

Use our multi-joint hinges & concepts and develop innovative solutions for your applications & requirements. To date, kabkin MJs are the first and only quality and industry standard for application-open kinematics worldwide.

  • Expertise in kinematics for 170 years
  • DIN EN ISO 9001 : 2015
  • Made in Germany
  • Over 1000 kinematic solutions
Individual consultationCAD modelsFree sample set
Mehrgelenkscharnier Edelstahl 140° Art.-Nr. 4597663 - Typ I
Multiple joint hinge Stainless steel 140°Type I
Multiple joint hinge Stainless steel 140°Type I
All-rounder with low installation depth
  • Opening angle: 140°
  • Load capacity flap shoring: 15 kg
  • Load capacity door shoring: max. 3 kg
  • Max. Flap/door thickness : 10 mm
Mehrgelenkscharnier Edelstahl 140° Art.-Nr. 4597665 - Typ II
Multiple joint hinge Stainless steel 140°Type II
Multiple joint hinge Stainless steel 140°Type II
All-rounder with higher load capacity
  • Opening angle: 140°
  • Load capacity flap shoring: 22 kg
  • Load capacity door shoring: max. 3 kg
  • Max. Flap/door thickness : 20 mm
Mehrgelenkscharnier Edelstahl 180° Art.-Nr. 4597667 - Typ III
Multiple joint hinge Stainless steel 180°Type III
Multiple joint hinge Stainless steel 180°Type III
Specialist with large opening angle
  • Opening angle: 180°
  • Load capacity flap shoring: 22 kg
  • Load capacity door shoring: max. 3 kg
  • Max. Flap/door thickness : 12 mm
Mehrgelenkscharnier Edelstahl 125° Art.-Nr. 4597669 - Typ IV
Multiple joint hinge Stainless steel 125°Type IV
Multiple joint hinge Stainless steel 125°Type IV
Specialist for recessed floor hatches
  • Opening angle: 125°
  • Load capacity flap shoring: 40 kg
  • Load capacity door shoring: max. 3 kg
  • Max. Flap/door thickness : 40 mm
Mehrgelenkscharnier Edelstahl 160° Art.-Nr. 4597761 - Typ V
Multiple joint hinge Stainless steel 160°Type V
Multiple joint hinge Stainless steel 160°Type V
Specialist for thicker flaps
  • Opening angle: 160°
  • Load capacity flap shoring: 30 kg
  • Load capacity door shoring: max. 3 kg
  • Max. Flap/door thickness : 25 mm
Mehrgelenkscharnier Edelstahl 180° Art.-Nr. 4598212 - Typ VI
Multiple joint hinge Stainless steel 180°Type VI
Multiple joint hinge Stainless steel 180°Type VI
Specialist with large opening angle and higher load capacity
  • Opening angle: 180°
  • Load capacity flap shoring: 30 kg
  • Load capacity door shoring: max. 3 kg
  • Max. Flap/door thickness : 22 mm
Mehrgelenkscharnier Aluminium 180 Art.-Nr. 3584350 - Typ VII
Multiple joint hinge Aluminium 180Type VII
Multiple joint hinge Aluminium 180Type VII
Specialist for high design demands and high load capacity
  • Opening angle: 180
  • Load capacity flap shoring: 100 kg
  • Load capacity door shoring: 100 kg
  • Max. Flap/door thickness : 13 mm
Mehrgelenkscharnier Stahl 90° Art.-Nr. 4598276 - Typ VIII
Multiple joint hinge Stahl 90°Type VIII
Multiple joint hinge Stahl 90°Type VIII
Specialist for small installation spaces
  • Opening angle: 90°
  • Load capacity flap shoring: 12 kg
  • Load capacity door shoring: max. 3 kg
  • Max. Flap/door thickness : 22 mm

Multiple joint hinges

Multiple joint hinges - kinematic solutions for the highest demands

Multiple joint hinges are the premier class of kinematics: they combine complex motion sequences with precise functionality and individual customization. Kabkin develops and supplies Multiple joint hinges that are precisely tailored to your requirements - from prototypes to series solutions.

With Kabkin, you combine kinematics, engineering and product development in one step: one prompt is all it takes to get your customized Multiple joint hinge - tailored to your design, opening angle, support and load capacity.

Request advice

A portrait of the Multiple joint hinge:

The development of Multiple joint hinges requires the highest precision in engineering and product design. Kabkin combines kinematic analysis with modern product development to design hinges that are both functional and durable. Each hinge is individually adapted to the user's requirements - whether for mechanical engineering, furniture and interior design or industrial applications. The prompt-to-product approach means you get a tailor-made Multiple joint hinge that perfectly combines design, function and kinematics.

A central criterion for Multiple joint hinges is the possible opening angle. Kabkin hinges are designed to enable precise and stable movements from small angles up to 180°. This makes them suitable for a wide range of applications - from doors and flaps to technical housings and complex movable constructions. Depending on the project, the opening angle can be flexibly adapted and optimized so that your solution always fits the required kinematics perfectly.

Multiple joint hinges from Kabkin can be screwed or mounted onto a wide range of materials. Whether steel, aluminum, wood or high-strength plastics - the construction is designed to ensure a reliable connection and permanent load-bearing capacity. This versatility makes Kabkin hinges universally applicable: from industrial environments to design applications. Thanks to the kinematic design, each hinge is optimally matched to the respective material, so that accuracy of fit and ease of installation are always guaranteed.

Stability and load-bearing capacity are decisive factors for Multiple joint hinges. Kabkin develops solutions that cover both lightweight applications in the furniture sector and heavy-duty constructions with loads in the three-digit kilogram range, depending on requirements.

Discover Proofs for Multiple joint hinges

Our heavy-duty, precise and safe multiple joint hinges meet all requirements for complex movement sequences: from lifting to opening and pivoting. This makes them the ideal and durable solution for demanding applications in hatches and doors, but also in robotics, automotive, aerospace and electronics.
